Material:
(1) Coil Width: 1000 mm
(2) Suitable Coil Thickness: 0.3mm ~ 0.6mm
(3) Suitable Raw Materials:
Pre-painted Coil; Yield bearing stress: 235MPa
Machine Components:
(1) Manual Un-coiler 1 set
(2) Roll-Forming M/C 1 set
(3) Hydraulic Pressing Die/Cutting M/C 1 set
(4) PLC Control System 1 set
Technical Specification
(1)Manual Un-coiler:
Un-powered; max.capacity:5 ton
*Hydraulic Un-Coiler(option):
Hydraulic system to expand coil inner hole;
Frequency Inverter to regulate turning speed;
Automatic stop device;Load capacity = Max.5Tons;
(2) Roll-Forming M/C: |
